Description of product -Android DVB/T/T2/IPTV STB GBOX G4-AD951
The world of Digital and IPTV has rapidly evolved in its relatively short history - from MPEG-2 to MPEG-4, SD to HD - and a host of other standards and features to suppot the delivery of TV services over managed broadband networks. With HD services are becoming an in -room requirement in many guest rooms worldwide, the Herodroid AHBOX7 allows hospitality solution providers to specify a high performing HD Android STB , based on the latest generation system -on-chip (SoC), but at a costeffective price point, whilst still providing all the features required for such applications.
ADVANTAGES & FEATURES
The Global Satcom G2-AH951 is an ideal component of a digital guest room entertainment solution. Fully digital systems provide numerous benefits for the operator, including:
- Easy update of content via remote download - no more tapes or CDs to track and ship
- Remote management of the system -fewer on-site service calls
- Ability to integrate with other guest services-telephony ,Interest,billing,information.
- Supports multiple streaming protocol UDP, RTSP, HLS, HTTP
- Act as Inroom wifi access point for Guest Internet usage inside the Rooms
- Hospitality system integrators require access to the STB to integrate applications for many installations. The G2-AH951 can be used as a connection for HeroApps interface to communicate and execute the need for hospitality solution.
- Hospitality televisions for single-remote-control use with Global Satcom G2-AH951
- The Global Satcom G2-AH951 is supported by an extensive ecosystem of Global Satcom middleware, conditional access and DRM options required for the widely varying configurations of the IPTV market.
SPECIFICATIONS
OTT+DVB-S2+DVB-T2
HARDWARE
- CPU : Amlogic S905W Quad core ARM Cortex-A53 CPU up to 1.5GHZ(DVFs)
- GPU : Penta-core ARM Mali-450 upto 750MHZ + DVFs
- RAM : DDRIII 2GB
- EMMC FLASH : EMMC FLASH 16GB
- WiFI : 2.4ghz 802.11 b/g/n
- IR : IR Infra Remote Control
- LED indicator : Red LED Standby, Blue Led Run
- IPTV : IPT System standard Support Multicast Multiple stramning protocol UDP,RTSP,HLS,HTTP Interactive GUI, Two way communication Protocol INPUT-HDMI, Rj45, IP protocol
- DVB-T/T2 : DVB_T2 system standard : ETSIEN 302 755 : Support MPLP Demodulation: QPSk,16QAM,64QAM or 256QAM Forward error correction rate 1/2,2/3,3/4,3/5,5/6 Guard interval: 1/4,19/256;1/8,19/128;1/16,1/32,1/128 Bandwith 6/7/8MHZ, Input Frange range: 54--860MHz input impedance:75 Input Signal level: 84 dBm to 0 dBm(average power)
-
DVB-S/S2 Demodulation
- DVB-S/S2 : DVB_T2 system standard Forward error correction rate 1/2,2/3,3/4,3/5,5/6,8/9,9/10 Input RF Frequency : 950MHZ to 2150MHz Code Rates : 1/2,2/3,3/4,5/6,7/8 FFT Mode : 2k,8k Symbol Rates: 1-55Msps
- Operating System : Android 9 OS
- Video Decoding : -VP9 Profile-2 up to 4K*2K@30fps
- -H.265 HEVC MP-10@L5.1 up to 4K*2K@30fps
- -H.264 AVC HP@L5.1 up to 4K*2K@30fps
- -H.264 MVC upto 1080P@60fps
- MPEG-4 ASP@L5 up to 1080P@60fps(ISO-14496)-WMV/VC-1 SP/MP/AP upto 1080P@60fps-AVS-P16(AVS+)/AVS-P2 JiZhun Profile upto 1080P@60fps
- -MPEG2 MP/HL up to 1080P@60fps
- -MPEG1 MP/HL up to 1080P@60fps
- -RealVideo 8/9/10 up to 1080P@60fps
- -Low latency 1080P H.264 60fps encoder
- -HDR10 and HLG HDR Video Processing
- Supports *.mkv*,*.mpg*,*.wmv*,*.mpeg*,*.dat*,*.avi*,*.mov*,*.iso*,*.mp4*,*.rm and .jpg* file formats
- -Video/Picture Encoding
- -Independent JPEG and H.264 encoder with configurable performance/bit-rate-JPEG image encoding
- Audio Decoding : -H.264 video encoding up to 1080P@60fps with low latency Low Power Media CPU with DSP audio processing Supports MP3,AAC,WMA,RM,FLAC,Ogg and programmable with 7.1/5.1 down-mixing Built-in stereo audio DAC Built-in SPDIF/IEC958 and PCM serial digital audio input/output Supports concurrent dual audio stereo channel output with combination of analog + PCMo or 125 + PCM
- Picture : JPEG,PNG,BMP,GIF,JPG
- Chinese,English,Germany,Japanese,Korea etc..24 languages
- KODI : Support KODI 17.1
- Remote : Support Infra Remote Control
- Applications Online : Browse all video websites , support Netflix, Hulu, Flixster, youtube, etc..
- Apps : Apps download freely from android market,amazon appstore etc
- medium : Local Media Playback , support HDD, U disc, HD card
- Talk Online : Support SKYPE video call, MSN, facebook, twitter, QQ etc
- Others : Support wifi hotpoint could be as a wireless router support DLNA ,Airplay , Google TV Remote etc.
- Accessories : Gift box HDMI cable optional IR remote control Power charger adapter 12V/1A User Manual
- Loading : Machine size Loading machine weight : Loading for 40GP : Packaged size and Packaged weight Loading for 20HQ
DVB-T/T2 Demodulation
